Specification
| System |
| CPU |
Quad Core ARM Cortex-A53 |
| GPU |
Mali-450 |
| Memory |
2GB |
| Flash |
16GB |
| WiFi |
WLAN 802.11a/b/g/n/ac |
| Bluetooth |
BT 4.0 |
| I/O |
1*HD |
4K*2K UHD Output |
| 1*USB |
1*USB 2.0 |
| 1*IR Reciver |
Remote Reciver Connect |
| 1*DC |
5V/2A |
| 1*AV |
480i/576i for CVBS |
| Software |
| OS |
Android 13.0 |
| Video |
Video Decoder
Real-time video decoder of
MPEG-1, MPEG-2, MPEG-4
H.263, H.264/AVC, H.265/HEVC, MVC
VC-1
AVS, AVS+,AVS2
MMU Embedded
Supports frame timeout interrupt, frame finish interrupt and bit stream error interrupt
Output data format YUV420 semi-planar, YUV400(monochrome), YUV422 is
supported by H.264
H.264/AVC BP/MP/HP profile @ level 5.1; H.264/AVC MVC; up to 4Kx2K @ 60fps
H.265/HEVC Main/Main10 profile @ level 5.1 High-tier; up to 4Kx2K @ 60fps
AVS2 4KX2K @60fps
MPEG-1, Main profile, up to 1080P @ 60fps
MPEG-2, SP@ML, MP@HL, up to 1080P @ 60fps
MPEG-4, ASP profile @ level 5, up to 1080P @ 60fps
AVS, Jizhun profile @ level 6.0; up to 1080P @ 60fps
AVS-P16 (AVS+), up to 1080P @ 60fps
H.263, up to 576P @ 60fps
VC-1, SP@ML, MP@HL, AP@L0-3, up to 1080P @ 60fps
Video Encoder
Support video encoder for H.264, [email protected]
H.264 maximum frame rate is up to 1920×1080 @60fps
Capable of encoding HEVC Main Profile @ L4.1 High-tier
H.265 resolution and frame rate are up to 1920×1080 @60fps
JPEG encoder included
JPEG decoder
Input JPEG file : YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 sampling formats
Output raw image : YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 semi-planar
Decoder size is from 48×48 to 8176×8176(66.8Mpixels)
Support JPEG ROI(region of image) decode
Maximum data rate is up to 76million pixels per second
Video OUT
Display Interface
Support HD 2.0b output up to 4K 10bit @60Hz
TV interface: TV encoder 10bit out for DAC
HD interface:
24 bit (RGB888 YCbCr444), 30 bit(RGB101010,YCbCr 420, YCbCr 444)
Max output resolution 4K for HD, 480i/576i for CVBS
HD
Compliant HD 2.0b
Support YUV420 4k x 2k @ 60fps
Support for 4k x 2k and 3D video formats
Support for up to 10.2bps bandwidth
Compliance HD compliance Test specification 1.4 and 2.x |
| Audio |
Supports MP3, AAC, WMA, RM, FLAC |
| Image |
HD JPEGBMPGIFPNGTIF |
| Language |
Multi-Language |
| Appliactions |
| Online |
Browse all video websites,support Netflix,Hulu,Youtube, etc. |
| Apps |
Apps download freely form Google PlayApkpure store etc. |
| Medium |
Local Media playback,Support HDD, U Disck |
| Talk online |
Support SKYPE ,MSN , facebook ,twitter ,QQ etc |
| Others |
Support Email,office suit etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard |
| Packing |
| Product dimension: 96*96*16.8mm |
| Unit products (G.W.): 122g |
| Unit packing: 175*103*53mm |
| Unit packing (G.W.): 356.5g |
| Accessories |
| HD cable *1 |
IR Remote *1 |
User Manual *1 |
Package box *1 |
Power adapter *1 |
